Fusion CP-FR5020 Performance Series 5.25" 2-Way Full Range Speakers

Delivering High Audiophile Performance from Speaker Features Normally Only Found in High-End Home Audio!

Features:

• Injection molded polypropylene cone - A lighter, thinner yet more rigid cone material.
• Large magnet assembly - High-efficiency output, high power handling.
• Silk dome tweeters - Very accurate, high-frequency response tweeters.
• FFFT ferro fluid-filled tweeters - High heat dissipation - greater reliability.
• 5"x7" Adapter Plate

Specifications:

• Basket: Steel Frame
• Cone Material: IMPP
• Frequency Response: 35Hz-25kHz
• Peak Power (Watts): 220
• Rated Power (Watts): 40
• Protection Boot: Yes
• Sensitivity (dB): 88
• Surround Material: PU

Thiele Small Parameters:

• Compliance (Cms) (?M/N): 914.263
• Cone Area (Sd) (cm²): 82
• D.C. Coil Resistance (Re) (Ohm): 3.2
• Diaphragm Mass (Mmd) (Kg): 0.00743
• Electrical Q (Qes): 0.489
• Force Factor (Bl) (TM): 4.378
• Free Air Resonance (Fs): 59.395
• Mechanical Q (Qms): 3.447
• Total Loudspeaker Q (Qts): 0.428
• VAS (CuFt): 0.308
• VAS (L): 8.729
• Voice Coil Impedance: 4 Ohm

Mounting Dimensions:

• Mounting Depth: 2-1/4"
• Mounting Diameter: 4-13/16"
• Weight: 6.50kg
